IMPROVED SITUATION AWARNESS
CRYSTAL CLEAR IMAGE WITH ADVANCED VIDEO PROCESSING
STANDARD INTERFACES FOR SEAMLESS INTEGRATION
MADE IN FRANCE
NoxCore HD are High Definition Infrared Camera Cores, and are the latest addition to the surveillance and security product portfolio. Based on latest generation of NoxEngine Technology, NoxCore HD provides unmatched performance together with seamless integration effort.
NoxCore HD is dedicated to applications where cutting edge technologies are required. It provides increased situation awarness thanks to its larger field of view, compared to SD variants.
Equipped with the latest generation of thermal detector, cooled by stirling engine, NoxCore HD cores offer extreme performance in a reduced footprint and energy consumption.
The Noxant team is dedicated to provide you with in-depth assistance for the optimal integration of NoxCore Vision in your system, and trains your team to get the maximum out of the NoxEngine technology.
We only present general information in our product pages. Enumerating all the possibilities would make reading tedious. In addition, your project is definitely unique. It is important that we discuss it together, don’t hesitate to contact us.
NoxCore HD is part of NoxCore Family.
Check other type of configurations available.
VIDEO AND CONTROL INTERFACES
- Video Output Format :
Color HDMI 720p with color overlay
Optional SDI or Analog
- Video Streaming :
h.264 : RTSP or UDP
RAW : GigEVision
- Control :
RS232 or Ethernet IP
- Cooled, snapshot FPA
- Spectral Range : MWIR – 3μm to 5μm
- Matrix size : 1280 x 720 pixels
- Pitch 10μm
- Optical aperture f/4
- Cooling by Rotary Stirling
- Cooldown Time @20°C <6min
PHYSICAL AND ENVIRONMENT SPECIFICATIONS
- <20W in steady operation @24VDC
- Power Supply : 24VDC
- Operating Temperature Range : -30°C to +65°C
- Storage Temperature Range : -40°C to +70°C
- Vibration : Operational 2g, IEC 68-2-29
- Shock : Operational 25g, IEC 68-2-26
NOXCORE HD INTEGRATION EXAMPLE
